DirectAir PHRVR200-HE

PART 463902
TBD
QUANTITY

About this item

DirectAir PHRVR200-HE heat recovery ventilator

he PHRVR200-HE is ideal for high-rise apartment applications, condominiums, single and multi family homes. With a completely new design the PHRVR200-HE features a Counterflow core, round metal collars and a high efficiency rating!

Features

•    Electronic balancing system
•    Silent and economical
•    Integrated door balancing ports
•    6” (152mm) round metal duct connections with rubberized duct seals
•    Top port design fits in tight spaces
•    Includes wall mounting
•    Counterflow heat recovery core
•    Multiple speed operation
•    Recirculating defrost sequence
•    Weight: 56.9 lbs (25.8kg) including core

Fans: Two (2) factory-balanced fans with backward curved blades. Motors come with permanently lubricated, sealed ball-bearings to guarantee long life and maintenance-free operation.

Heat Recovery Core: Counterflow heat recovery exchanger built from thermoformed polymer plates covered by a limited lifetime warranty. Core dimensions are 14.4” x 14.4” (366 x 366 mm) with a 14” (355 mm) depth. Our heat exchangers are designed and manufactured to withstand extreme temperature variations.

Defrost Sequence: The unit incorporates a unique and quiet internal recirculation defrost that does not depressurize the home during the defrost cycle. A preset defrost sequence is activated when the outdoor temperature falls below 23° F (-5° C) and automatically adjusts itself based on operating conditions. The fan speed is also adjusted automatically to provide a smooth and quiet transition between Ventilation & Defrost mode.

Serviceability: Core, filters, fans and electronic panel can be accesses easily from the access panel. Core conveniently slides out with only 16” (406 mm) clearance.

Duct Connections: 6” (152mm) round metal duct connections with rubberrized seal.

Cabinet: 22 gauge galvanized steel corrosion resistant with pre-painted access door

Insulation:Cabinet is fully insulated with 3/4” (20 mm) high density expanded polystyrene.

Filters:Two (2) washable electrostatic panel type air filters 7.87” (200mm) x 13.77” (350mm) x 0.125” (3mm).

Balancing and commissioning:Balancing must be completed using the STS2.0 Programmable Touch Screen Wall Control

Warranty:Limited lifetime on counterflow exchanger, 7 year on motors, and 5 year on parts.



Make & Model
Brand ---
Part # ---
Specifications
Color Family White
Certifications & Standards
TAA/BAA Compliant 1
Packaging Dimensions
Height 7.800

There are currently no resources for this product.
