Eaton Edison ECNR fuse, Time-delay current-limiting fuse, Superior overload and cycling capabilities, 3 A, Dual, Class RK5, Non-indicating, Ferrule end x ferrule end, 8 sec at 500%, 200 kAIC, Standard, 250 V, 125 Vdc.

GENERAL SPECIFICATIONS

PRODUCT NAME

Eaton Edison ECNR fuse

CATALOG NUMBER

ECNR3

UPC

782634506997

PRODUCT LENGTH/DEPTH

2 in

PRODUCT HEIGHT

.56 in

PRODUCT WIDTH

.56 in

PRODUCT WEIGHT

.5 lb

WARRANTY

Not Applicable

COMPLIANCES

CE Marked

ELECTRICAL RATING

AMPERAGE RATING

3 A

INTERRUPT RATING

200 kAIC

RESPONSE TIME

8 sec at 500%

VOLTAGE RATING

250 Vac, 125 Vdc

PHYSICAL DETAILS

NUMBER OF ELEMENTS

Dual

PACKAGING TYPE

Standard

GENERAL INFORMATION

CLASS

Class RK5

FUSE INDICATOR

Non-indicating

SPECIAL FEATURES

Non current limiting
